TP-5710-17 – 17″ Fanless Panel PC with 9th Gen Core i5 CPU

  • 17” Fully Flat Touchscreen
  • Intel 9th Generation 6-Core i5 CPU
  • Fanless Cooling System
  • Multiple inputs and outputs including 4x USB 3.1, 3x COM, 2x Lan, and 3x Display port 1.2
  • Windows 11 Capabilities

The TP-5710-17 is ideal for industrial environments where high computing power is needed. This panel PC comes equipped with a high TDP processor that we designed into a fanless chassis, encouraging more computing power while still running efficiently and quietly. The 17” design can come in either resistive or PCap touchscreens, with an IP66 rated front bezel to protect from spray or splashes. This is a modular Panel PC where the front monitor can be taken off for easy maintenance and cleaning. The Intel 6-Core i5 CPU allows for Windows 11 capabilities and improves the efficiency of your business with faster processing power.

SPECIFICATIONS

Primary Components

Processor Family Intel Core-I Series 9th Generation Coffee Lake
Processor Model Core i5-9500TE
Memory Type 2x DDR4 SO-DIMM
Memory Support 4GB, 8GB, 16GB, 32GB, 64GB
Storage type 1x 2.5″ SATA Drive Bay for SSD/HDD (easily accessible), 1x M.2 2280 NVME SSD slot
Storage support M.2 and 2.5″: 128GB – 1TB

Display

Screen Size 17″
Resolution 1280 x 1024 (SXGA)
Screen Ratio 5:4
Brightness 350 nits

Touch Screen

Touch Screen 5 Wire Resistive, Projected Capacitive (Multi-touch)
Hardness Resistive: 3H, P-cap: 7H

External I/O ports

USB 4x USB 3.1
Serial / Com 3x COM
Serial Protocol Detail 2x RS-232, 1x RS-232/422/485
Ethernet / LAN 2x RJ45 GbE LAN
Video Outputs 3x DisplayPort 1.2
Audio 1x Audio Line-Out, 1x Mic-In
Power Input Port 4-Pin DC-In (Phoenix Type Terminal Block)

Power

Input Voltage Range 19-28V DC
Standard Power Adapter Optional 150 watt, universal 100 ~240V AC in, 19V DC out, 7.8A

Operating Systems

Windows Windows 11 Pro, Windows 10 IoT, Windows 10 Pro
Linux Linux Ubuntu 20.04 or above

Compatibility

Security Hardware fTPM 2.0

Expansion Slots

Internal Mini PCIe 1x Mini-PCIe
Internal M.2 1x M.2 (for WiFi expansion option)
PCIe Slot 1x PCI-E (x16)
PCIe Expansion Details Single slot, max size 225x110mm, max power draw supported 25W

Thermal and Environmental

Operating Temperature 0°C – 50°C
(32°F – 122°F)
Storage Temperature -20°C – 60°C
(-4°F – 140°F)
Cooling Solution Passive – Fanless with Heatsink

Enclosure

Material Aluminum front bezel and SECC Steel Chassis
Ip Rating IP66 Front Bezel
Color Black
Mounting Options Panel Mount, VESA 75 Mount

Peripherals & Wireless Connectivity

WiFi Optional 802.11 ac + Bluetooth with External Antennas
BlueTooth Optional Bluetooth 4.0

Dimensions / Weight

Weight 9.4 KG (20.7 lbs)
Dimensions 426 x 358 x 125 mm (16.8 x 14.1 x 4.9 in)

Certification

Certifications CE, FCC

Warranty

Warranty Up to 5 Years
