The TM-5900-24 is an absolute powerhouse of a medical all-in-one PC. This medical computer comes standard with a high-performance 11th Generation Intel Tiger Lake processor, a 24″ full HD display, and a P-capacitive touchscreen, all packed into a slim and sleek all-in-one computer weighing only 16.5 lbs. The TM-5900-24’s light weight and slim profile, along with an optional battery pack, make it a perfect selection for mobile medical cart usage. This medical all-in-one also features dual microphones, a 5MP wide angle camera and optional speakers, so it’s also a great choice as a telemedicine station, or mobile entertainment center for hospital patients. Combine all of this with long-term support for seven years and guaranteed life cycle support until 2030, and you’re left with the most impressive medical all-in-one PC on the market today.
SPECIFICATIONS
Primary Components
| Processor Family | Intel Core I series 11th Generation Tiger Lake |
| Processor Model | Core i5-1135-G7 |
| Processor Speed | Up to 4.2 GHz |
| Memory Type | 2x DDR4 SO-DIMM |
| Memory Support | 8GB, 16GB, 32GB |
| Storage type | 1x 2.5″ SATA Drive Bay for SSD/HDD, 1x M2 |
| Storage support | M.2 and 2.5″: 128GB – 1TB |
Display
| Screen Size | 23.8″ |
| Resolution | 1920 x 1080 (Full HD) |
| Screen Ratio | 16:9 |
| Brightness | 250 nits |
| Contrast Ratio | 3000:1 |
| Viewing Angle | 178º (H), 178º (V) |
| Number of Colors Supported | 16.7M |
Touch Screen
| Touch Screen | Projected Capacitive (Multi-touch) |
External I/O ports
| USB | 4x USB 2.0, 4x USB 3.0 |
| Serial / Com | 1x COM |
| Ethernet / LAN | 2x RJ45 GbE LAN |
| Video Outputs | 1x HDMI |
| Audio | 1x 3.5mm Speaker Box Jack |
Power
| Input Voltage Range | 19V DC |
| Standard Power Adapter | 4.74 Amp AC/DC Adapter |
Battery
| Type | Removable 10.8V/9220mAh Battery |
| Operating Time | 2hrs |
| Quantity | 1x Optional Battery |
Operating Systems
| Windows | Windows 11, Windows 10 IoT, Windows 10 Pro |
Compatibility
| Security Hardware | TPM 2.0 |
Expansion Slots
| Internal Mini PCIe | 1x Mini-PCIe |
| Internal M.2 | 1x M.2 |
| Other | RFID |
| Expansion Module support | Speaker Box |
Multimedia
| Speakers | 2x 3W Speakers |
| Camera | 5MP Webcam |
| Microphone | 2x Built-in Microphones |
Thermal and Environmental
| Operating Temperature | 0°C – 40°C (32°F – 104°F) |
| Storage Temperature | -20°C – 60°C (-4°F – 140°F) |
| Cooling Solution | Passive – Fanless |
Enclosure
| Material | Die-Casting / Plastic |
| Ip Rating | IP65 Front Bezel |
| Color | White |
| Antibacterial Housing | Yes |
| Control Buttons | Audio Down, Audio Up, Brightness Down, Brightness Up, Touchscreen Lock for Cleaning |
| Mounting Options | VESA Mount |
Peripherals & Wireless Connectivity
| WiFi | Wifi 802.11 a/b/g/n/ac |
| BlueTooth | Bluetooth 5.2 |
| RFID | Optional RFID (LF/HF) |
| Peripheral Other | Camera Privacy Latch |
Dimensions / Weight
| Weight | 7.8 KG (17.2 lbs) |
| Dimensions | 581 x 351 x 43 mm (22.9 x 13.8 x 1.7 in) |
Certification
| Certifications | 60601-1 4th Edition, FCC Class B |
Warranty
| Warranty | 1 Year |
