Stainless Steel Panel PC equipped Intel Amston Lake Processor, Preinstalled with 8GB SO-DIMM DDR5, PCAP touch, 10~28V DC, 304 Stainless Steel Chassis. Full body IP66 Rated. Includes Water-Proof Connectors.
SPECIFICATIONS
System |
|
|---|---|
| CPU | Intel Atom® x7433RE Processor 6M Cache, up to 3.40 GHz / TDP 9w Intel Atom® x7835RE Processor 6M Cache, up to 3.40 GHz / TDP 12w |
| Memory Ext. | 1 x SO-DIMM DDR5-4800 up to 16GB (Pre-installed 8GB) (ECC supported) |
| Storage | 1 x M-Key 2280 (PCIe Gen3 x2) for M.2 SSD 1 x 128GB Emmc (optional) |
Communication |
|
| Wireless | IEEE 802.11ax 2T2R module (Wi-Fi 6E) with BT v5.2 (optional) |
I/O Interface |
|
| Ethernet | 2 x 2.5GbE LAN via Intel I226-IT |
| Expansion | 1 x M.2 M-Key 2242/2280 (PCIe Gen3 x1 + SATA) 1 x M.2 B-Key 3052/3080 (PCIe Gen3 x1 + USB 3.0 x1) 1 x NANO-SIM 1 x M.2 E-key 2230 (PCIe Gen3 x1 + USB 2.0 x1) for optional WIFI/BT module |
Power |
|
| Power Supply | DC 10 ~ 28V |
Environment |
|
| Operating Temperature | -30°C ~ 55°C @50%RH |
| Safety & EMC | CE, FCC (Class A) |
| Humidity | 10% ~ 90% (non-condensing) |
| Storage Temperature | -40°C ~ 70°C |
| IP Level | Fully IP66 |
Physical Characteristics |
|
| Color | silver |
| Mounting | Yoke / VESA 100mm |
LCD |
|
| Size | 15.6” |
| Resolution | 1920 x 1080 (16:9) |
| Brightness (cd/m2) | 450 cd/m² |
| Contrast Ratio | 800 : 1 |
| LCD Color | 16.2M |
| Pixel Pitch (mm) | 0.179 (H) x 0.179 (V) |
| Viewing Angle (H-V) | 178°/178° |
| Backlight MTBF | 50000 hours |
Touch |
|
| Touch Screen | PCAP with USB interface (anti-UV/AR coating) |
| Touch Controller | ILI2520 |
Other Features |
|
| Camera | 1 x Camera (Wide-viewing angle) |
I/O Interface |
|
| I/O Interface | 1 x CAN-bus (with 2.0 kV isolation) |
| 1 x DC Input Jack | |
| 1 x GPIO (with SMbus (1.6 KV isolation)) | |
| 2 x LAN (2.5GbE) | |
| 1 x Power Switch | |
| 1 x RS-232 (with 2.0 kV isolation) | |
| 1 x RS-232/422/485 (with 2.0 kV isolation) | |
| 1 x USB 2.0 | |
| 1 x USB 3.2 Gen1x1 | |
| VGA | |
ORDERING
| SHIELD-156-R4C-R10 | 15.6″ 450cd/m² 1920×1080 Panel PC with Intel® Atom x7835RE Processor, TDP 12W, Preinstalled with 8GB DDR5, PCAP touch, 10~28V DC, 304 Stainless Steel Chassis, Full body IP66 Rated with Water-Proof Connectors, R10 |
|---|---|
| SHIELD-156-R3C-R10 | 15.6″ 450cd/m² 1920×1080 Panel PC with Intel® Atom x7433RE Processor, TDP 9W, Preinstalled with 8GB DDR5, PCAP touch, 10~28V DC, 304 Stainless Steel Chassis, Full body IP66 Rated with Water-Proof Connectors, R10 |
PACKAGE CONTENTS
| Package Contents |
|
|---|
OPTIONS
