  • Robust and durable, all-metal enclosure, sealing design, full IP67 waterproof, customized with 5 Meter Sealed I/O with cable set included.
  • 18.5 inch Industrial LCD panel, 1500 nits, sunlight readable. Anti glare.
  • With dimmer on the bezel, Can adjust the brightness to 0-100%.
  • Adopt EETI waterproof touch solution. touch can work well with drop water on the screen.
  • Optical bonding technology.
  • Wide Temperature Range: operating: -20 to 70°C, storage: -30 to 80°C.
  • High performance mainboard, 7x24 continuous operation.

    • The post SL185W – 18.5″ Full IP67 High Brightness Industrial Touch Screen Monitor appeared first on Miller Technologies.

    ]]>     18.5″ Robust and durable fully sealed IP67 industrial touch screen monitor with 1500 nit high brightness backlight. The SL185W includes a dimming sensor built into the bezel to automatically adjust the brightness to match ambient brightness. The SL185W features wide operating: -20 to 70°C, and storage: -30 to 80°C temperature ranges. Designed for 24/7 operation. Contact Us today for SL185W pricing.

    SPECIFICATIONS

    LCD panel
    Panel size 18.5″
    Resolution 1920*1080
    Aspect ratio 16:9
    Support Color 16.7M colors
    Brightness (cd/m²) 1500 nits, sunlight readable
    Surface treatment Anti glare
    Contrast ratio 1000:1
    View angle 80°/80°/80°/80° (R/L/U/D)
    Touch panel
    Touchscreen Type Project Capacitive Touch (10 points )
    Surface Hardness 7H
    Luminousness 90%
    Touch Interface USB (RS232 optional)
    Touch response time 2ms
    Working Life >50 million times
    Touch options (5 wires restive touch optional)
    Signal Ports
    VGA 1xVGA
    HDMI 1xHDMI
    DVI optional
    Audio in/out optional
    OSD
    OSD control Brightness, contrast ratio, auto adjustment, H/V position,  language select etc.
    Support languages English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese etc.
    Support OS Windows XP, Windwows /7/8/10, Linux, Mac OS X, Android, ect.
    Power Supply
    External Power Supply AC 100-240V
    Working voltage DC 12V
    Power consumption ≤40W
    Enclosure
    Material aluminium alloy front bezel + High strength cold rolled steel back case
    Color Black, white, Silver, color can be customized
    VESA mounting 75x75mm/100×100 mm
    IP-grade Full IP67 waterproof
    Operating Environment
    Temperature Range operating: -20 to 70°C, storage: -30 to 80°C
    Relative humidity operating: 10% to 90%, storage: 5% to 90%
    Packing Details
    Net weight 5.5 kg
    Gross weight 6.5 kg
    Product Dimension 50×30.1×5 cm
    Packing size 55x49x21 cm
    Accessories Power adapter, Waterproof Power cord, Waterproof VGA/HDMI/USB cable, Wall mount
    Other
    Mounting (options) 1) wall brackets for wall-mounting, VESA 100×100 mm
    2) stable metal holder to support the monitor
    Warranty 1 year warranty

    DIMENSIONS

    The post SL185W – 18.5″ Full IP67 High Brightness Industrial Touch Screen Monitor appeared first on Miller Technologies.

    ]]>         TCS2150 – 21.5″ Industrial Touch Screen Monitor https://millertech.com/product/tcs2150-21-5-industrial-touch-screen-monitor/?utm_source=rss&utm_medium=rss&utm_campaign=tcs2150-21-5-industrial-touch-screen-monitor Tue, 17 Jan 2023 14:58:08 +0000 https://millertech.com/?post_type=product&p=10227
  • Slim Metal Housing
  • IPS Touch Type LCD Panel
  • Optional Open Frame Solution
  • Flexible and High Integration
  • 16:9 Full HD 1920 x 1080 Resolution
  • True Flat Panel with Multi P-Cap Touch

    • The post TCS2150 – 21.5″ Industrial Touch Screen Monitor appeared first on Miller Technologies.

    ]]>

    SPECIFICATIONS

    Display
    CPU Novatek 68862
    Memory SPI Flash 2M bits
    Display Type 21.5″ TFT IPS LCD
    Resolution 1920 x 1080
    Brightness 250 nits
    Touch Panel 10 Points Projected Capacitive Touch Panel
    Viewing Angle Horizontal 178° / Vertical 178°
    Contrast Ratio 3000:1
    Response Time 18 ms
    IO Ports 1 x HDMI
    1 x USB (For Touch)
    Physical
    Audio 2 x 3W Speaker
    Color Black
    Mounting VESA Mount 100 x 100
    Housing Metal
    Power Adapter DC 12V/5A, 60W
    Standard Accessory 1 x Power Adapter (12V/5A)
    Product Dimension 530.5 x 321.2 x 36 mm
    Product Weight 4.2kgs
    Environment
    Certification CE, FCC
    Operating Temperature 0°C ~ 40°C
    Storage Temperature -10°C ~ 55°C
    Relative humidity 10%~ 70% (non-condensing)

    DIMENSIONS

    The post TCS2150 – 21.5″ Industrial Touch Screen Monitor appeared first on Miller Technologies.

    ]]>         NEMAview 120 – 12″ Industrial Panel Mount Monitor https://millertech.com/product/nemaview-120/?utm_source=rss&utm_medium=rss&utm_campaign=nemaview-120 Fri, 05 Feb 2021 14:36:15 +0000 https://millertech.com/?post_type=product&p=7420 Product Overview The innovative NEMAview™ 120 is a 12″ Industrial Panel Mount Monitor that provides a perfect solution for any industrial panel monitor application. The rugged cast aluminum front bezel provides a thin transition to the mounting surface. The slim panel gives a sleek and finished look. A special plastic gasket prevents liquid, dust and contaminates […]

    The post NEMAview 120 – 12″ Industrial Panel Mount Monitor appeared first on Miller Technologies.

    ]]>     Product Overview
    The innovative NEMAview™ 120 is a 12″ Industrial Panel Mount Monitor that provides a perfect solution for any industrial panel monitor application. The rugged cast aluminum front bezel provides a thin transition to the mounting surface. The slim panel gives a sleek and finished look. A special plastic gasket prevents liquid, dust and contaminates from building up around the screen opening, providing NEMA 4X/IP65 compliance. Other panels use foam gaskets, which create a shelf for contaminates to build up on the gasket. The NEMAview™ Series includes 10″, 12″, 15″, 17″ and 19″ screen sizes.

    Special Panel Mounting
    NEMAview™ Sealed Panel Mount LCD monitors can be easily mounted to any cabinet or surface using our patent pending Panel Clamp. The Panel Clamp can adapt to almost any mounting thickness with extreme clamping force. Simply cut a hole in your panel to the designated size of the NEMAview™, turn the Panel Clamp, and then tighten. No more drilling holes for panel mount studs.

    Front Panel Control
    The Easy Control OSD (On Screen Display) keypad gives the ability to adjust brightness, contrast, power, and toggle from composite video to PC monitor mode with one key. Using the lock out mode, all functions are locked out to the user, even power.

    Connectivity
    Standard VGA, Composite Video, or S-Video input. Touch screen interface RS-232 or USB

    Touch Screen Options
    Three types of touch screens are available: resistive, capacitive, and infrared (IR). The various touch screen technologies give the flexibility you need to have the best touch screen technology for your environment and application.

    Optional Outdoor LCD Screens
    Options included various high bright outdoor LCD screens. Select from addition outdoor rated touch screens with AR coating, anti heat reflective filming and antireflective glare properties. Let our engineering department help you select the correct combination for your application.

    SPECIFICATIONS
    Enclosure: Sealed Rugged Cast Aluminum enclosure, adheres to NEMA 4X
    Dimensions:

    • NEMAview™ 110:
    • NEMAview ™ 120:
    • NEMAview™ 150: 14.000″ (H) x 17.000″ (W) x 2.369″ (D)
    • NEMAview™ 170: 15.750″ (H) x 18.500″ (W) x 2.648″ (D)
    • NEMAview™ 190: 17.000″ (H) x 20.000″ (W) x 2.767″ (D)

    Resolution / NIT (call for high bright\outdoor options)

    • NEMAview™ 110:
    • NEMAview ™ 120:
    • NEMAview™ 150 – 15.0” LCD: XGA – 1024×768 – 300 NIT
    • NEMAview™ 170 – 17.0” LCD: SXGA – 1280×1024 – 300 NIT
    • NEMAview™ 190 – 19.0” LCD: SXGA – 1280×1024 – 270 NIT

    Non-Operating Temperature: -20º to 60º C (all monitors)
    Operating Temperature: 0º to 50º C (all monitors)
    Operating Shock: 10g, 11ms, 1/2 sine
    Operating Vibration: .41g, 3-500 Hz
    Video Interface: DB15 VGA Female connector, Composite Video (NTSC, PAL, S-Video) interface
    Touch Screen Interface: DB9 Serial Female or USB connector
    Cable/Power: Each Monitor comes standard with 6ft Male-to-Male VGA DB15 extender cable, External power supply with cable.
    Made in the USA
    Other accessories are available upon request

    The post NEMAview 120 – 12″ Industrial Panel Mount Monitor appeared first on Miller Technologies.

    ]]>         NEMAView 110 – 10″ Industrial Panel Mount Monitor https://millertech.com/product/nemaview-110/?utm_source=rss&utm_medium=rss&utm_campaign=nemaview-110 Thu, 04 Feb 2021 19:12:25 +0000 https://millertech.com/?post_type=product&p=7414 Product Overview The innovative NEMAview™ 110 is a 10″ Industrial Panel Mount Monitor that provides a perfect solution for any industrial panel monitor application. The rugged cast aluminum front bezel provides a thin transition to the mounting surface. The slim panel gives a sleek and finished look. A special plastic gasket prevents liquid, dust and contaminates […]

    The post NEMAView 110 – 10″ Industrial Panel Mount Monitor appeared first on Miller Technologies.

    ]]>     Product Overview
    The innovative NEMAview™ 110 is a 10″ Industrial Panel Mount Monitor that provides a perfect solution for any industrial panel monitor application. The rugged cast aluminum front bezel provides a thin transition to the mounting surface. The slim panel gives a sleek and finished look. A special plastic gasket prevents liquid, dust and contaminates from building up around the screen opening, providing NEMA 4X/IP65 compliance. Other panels use foam gaskets, which create a shelf for contaminates to build up on the gasket. The NEMAview™ Series includes 10″, 12″, 15″, 17″ and 19″ screen sizes.

    Special Panel Mounting
    NEMAview™ Sealed Panel Mount LCD monitors can be easily mounted to any cabinet or surface using our patent pending Panel Clamp. The Panel Clamp can adapt to almost any mounting thickness with extreme clamping force. Simply cut a hole in your panel to the designated size of the NEMAview™, turn the Panel Clamp, and then tighten. No more drilling holes for panel mount studs.

    Front Panel Control
    The Easy Control OSD (On Screen Display) keypad gives the ability to adjust brightness, contrast, power, and toggle from composite video to PC monitor mode with one key. Using the lock out mode, all functions are locked out to the user, even power.

    Connectivity
    Standard VGA, Composite Video, or S-Video input. Touch screen interface RS-232 or USB

    Touch Screen Options
    Three types of touch screens are available: resistive, capacitive, and infrared (IR). The various touch screen technologies give the flexibility you need to have the best touch screen technology for your environment and application.

    Optional Outdoor LCD Screens
    Options included various high bright outdoor LCD screens. Select from addition outdoor rated touch screens with AR coating, anti heat reflective filming and antireflective glare properties. Let our engineering department help you select the correct combination for your application.

    SPECIFICATIONS
    Enclosure: Sealed Rugged Cast Aluminum enclosure, adheres to NEMA 4X
    Dimensions:

    • NEMAview™ 110:
    • NEMAview ™ 120:
    • NEMAview™ 150: 14.000″ (H) x 17.000″ (W) x 2.369″ (D)
    • NEMAview™ 170: 15.750″ (H) x 18.500″ (W) x 2.648″ (D)
    • NEMAview™ 190: 17.000″ (H) x 20.000″ (W) x 2.767″ (D)

    Resolution / NIT (call for high bright\outdoor options)

    • NEMAview™ 110:
    • NEMAview ™ 120:
    • NEMAview™ 150 – 15.0” LCD: XGA – 1024×768 – 300 NIT
    • NEMAview™ 170 – 17.0” LCD: SXGA – 1280×1024 – 300 NIT
    • NEMAview™ 190 – 19.0” LCD: SXGA – 1280×1024 – 270 NIT

    Non-Operating Temperature: -20º to 60º C (all monitors)
    Operating Temperature: 0º to 50º C (all monitors)
    Operating Shock: 10g, 11ms, 1/2 sine
    Operating Vibration: .41g, 3-500 Hz
    Video Interface: DB15 VGA Female connector, Composite Video (NTSC, PAL, S-Video) interface
    Touch Screen Interface: DB9 Serial Female or USB connector
    Cable/Power: Each Monitor comes standard with 6ft Male-to-Male VGA DB15 extender cable, External power supply with cable.
    Made in the USA
    Other accessories are available upon request

    The post NEMAView 110 – 10″ Industrial Panel Mount Monitor appeared first on Miller Technologies.

    ]]>         TD-45-22 – 21.5″ IP66 Industrial Touchscreen Monitor https://millertech.com/product/td-45-22-21-5-ip66-industrial-touchscreen-monitor/?utm_source=rss&utm_medium=rss&utm_campaign=td-45-22-21-5-ip66-industrial-touchscreen-monitor Wed, 29 Apr 2020 19:56:40 +0000 https://millertech.com/?post_type=product&p=6165
  • 21.5" LCD High Resolution Touchscreen
  • Rugged Die Cast Aluminum Enclosure
  • Optional Sunlight Readable 1000 Nit LCD
  • IP66 Compliant Flat Front Panel
  • Available with Resistive or Projected Capacitive Touchscreen
  • Wide Range DC 9~36V Power Input

    • The post TD-45-22 – 21.5″ IP66 Industrial Touchscreen Monitor appeared first on Miller Technologies.

    ]]>     The TD-45-22 is the largest industrial touchscreen monitor in this series with a 21.5” LCD display. This monitor can be panel mounted into a cutout in an enclosure or it can be mounted to an arm, stand, or hung on a surface. When panel mounted, the front bezel is IP66 rated and protected from liquids and dust. The TD-45-22 can be connected to a fanless box PC, for a rugged, long-life solution, or to another touchscreen PC, where it can operate as a cloned or extended display. The same model is available in screen sizes down to 7″ to meet the needs of most applications. These industrial touchscreen monitors may be mounted into control cabinets, integrated onto an OEM machine, or used in a manufacturing environment. CONTACT US for a TD-45-22 quote today.

    SPECIFICATIONS

    Display

    Screen Size 21.5″
    Resolution 1920 x 1080 (Full HD)
    Screen Ratio 16:9
    Brightness 250 nits, Optional 1000 nit High Brightness
    Contrast Ratio 3000:1
    Viewing Angle 178º (H), 178º (V)
    Number of Colors Supported 16.7M

    Touch Screen

    Touch Screen Projected Capacitive, Resistive
    Light Transmission Over 80% (Resistive), Over 90% (P-Cap)
    Lifetime Usage 30,000 hrs, 50,000 hrs (High Brightness)

    External I/O ports

    USB 1x USB Type B Default (Optional RS-232 DB9)
    Video Inputs 1x HDMI, 1x DVI-D, 1x DisplayPort, 1x VGA
    Audio 1x Optional Speaker with 1x Audio Input
    Power Input Port 3-Pin DC-In (Phoenix Type)

    Power

    Input Voltage Range 9-32V DC
    Max Power Consumption 18.3W (Resistive), 24.9W (P-Cap)
    Standard Power Adapter Optional 12V AC/DC Adapter

    Multimedia

    Speakers Optional Speaker

    Thermal and Environmental

    Operating Temperature -20°C – 60°C
    (-4°F – 140°F)
    Storage Temperature -30°C – 70°C
    (-22°F – 158°F)
    Storage Humidity 10% – 90% Non-condensing
    Cooling Solution Passive – Fanless

    Enclosure

    Material Aluminum
    IP Rating IP66 Front Bezel, Optional IP69K
    Color Silver
    Mounting Options Panel Mount, VESA 100 Mount

    Dimensions / Weight

    Weight 7.6 KG (16.8 lbs)
    Dimensions 557 x 362 x 64.8 mm (21.9 x 14.3 x 2.6 in)

    Certification

    Certifications CE, FCC Class A

    Warranty

    Warranty Up to 5 Years



    The post TD-45-22 – 21.5″ IP66 Industrial Touchscreen Monitor appeared first on Miller Technologies.

    ]]>         TD-45-19 – 19″ IP66 Industrial Touchscreen Monitor https://millertech.com/product/td-45-19-19-ip66-industrial-touchscreen-monitor/?utm_source=rss&utm_medium=rss&utm_campaign=td-45-19-19-ip66-industrial-touchscreen-monitor Wed, 29 Apr 2020 19:46:40 +0000 https://millertech.com/?post_type=product&p=6159
  • 19" LCD with 1280 x 1024 Resolution
  • Aluminum Die Cast Chassis
  • Optional Sunlight Readable 1000 Nit LCD
  • Wide Range DC 9~36V Power Input
  • Full Flat Front Panel
  • Available with Resistive or Projected Capacitive Touchscreen

    • The post TD-45-19 – 19″ IP66 Industrial Touchscreen Monitor appeared first on Miller Technologies.

    ]]>     The TD-45-19 is a touchscreen panel display made for industrial environments. This cost effective, versatile display has a die-cast aluminum enclosure and can be panel mounted into a cutout in an enclosure or it can be mounted to an arm, stand, or hung on a surface. When panel mounted, the front bezel is IP66 rated and protected from liquids and dust. The TD-45-19 provides a graphical user interface where the operator may perform tasks such as: operate a machine, view sensor data, or interact with ERP software. This touchscreen monitor can be connected to a rugged box PC or another panel PC. The same model is available in screen sizes from 7″ to 21.5″. CONTACT US for a TD-45-19 quote today.

    SPECIFICATIONS

    Display

    Screen Size 19″
    Resolution 1280 x 1024 (SXGA)
    Screen Ratio 4:3
    Brightness 350 nits, Optional 1000 nit High Brightness
    Contrast Ratio 1000:1
    Viewing Angle 170º (H), 160º (V)
    Number of Colors Supported 16.7M

    Touch Screen

    Touch Screen Projected Capacitive, Resistive
    Light Transmission Over 80% (Resistive), Over 90% (P-Cap)
    Lifetime Usage 50,000 hrs

    External I/O ports

    USB 1x USB Type B Default (Optional RS-232 DB9)
    Video Inputs 1x HDMI, 1x DVI-D, 1x DisplayPort, 1x VGA
    Audio 1x Optional Speaker with 1x Audio Input
    Power Input Port 3-Pin DC-In (Phoenix Type)

    Power

    Input Voltage Range 9-32V DC
    Max Power Consumption 16.8W (Resistive), 18.3W (P-Cap)
    Standard Power Adapter Optional 12V AC/DC Adapter

    Multimedia

    Speakers Optional Speaker

    Thermal and Environmental

    Operating Temperature -20°C – 60°C
    (-4°F – 140°F)
    Storage Temperature -30°C – 70°C
    (-22°F – 158°F)
    Storage Humidity 10% – 90% Non-condensing
    Cooling Solution Passive – Fanless

    Enclosure

    Material Aluminum
    IP Rating IP66 Front Bezel
    Color Silver
    Mounting Options Panel Mount, VESA 100 Mount
    Approved Cleaning Solutions Alcohol, Chlorine and Compounds, Glutaraldehyde, Hydrogen Peroxide, Ortho-phthalaldehyde (OPA), Quaternary Ammonium Compounds

    Dimensions / Weight

    Weight 6.2 KG (13.7 lbs)
    Dimensions 468 x 380 x 64.8 mm (18.4 x 15.0 x 2.6 in)

    Certification

    Certifications CE, FCC Class A

    Warranty

    Warranty Up to 5 Years



    The post TD-45-19 – 19″ IP66 Industrial Touchscreen Monitor appeared first on Miller Technologies.

    ]]>         TD-45-18 – 18.5″ IP66 Industrial Touchscreen Monitor https://millertech.com/product/td-45-18-18-5-ip66-industrial-touchscreen-monitor/?utm_source=rss&utm_medium=rss&utm_campaign=td-45-18-18-5-ip66-industrial-touchscreen-monitor Wed, 29 Apr 2020 19:37:53 +0000 https://millertech.com/?post_type=product&p=6152
  • 18.5" LCD with 1366 x 768 Resolution
  • Optional Sunlight Readable 1000 Nit LCD
  • Rugged Die Cast Aluminum Enclosure
  • Full Flat Front Panel and Fanless Design
  • Available with Resistive or Projected Capacitive Touchscreen
  • Wide Range DC 9~36V Power Input

    • The post TD-45-18 – 18.5″ IP66 Industrial Touchscreen Monitor appeared first on Miller Technologies.

    ]]>     The TD-45-18 is a cost effective, versatile display with a die-cast aluminum enclosure, ideal for industrial environments. This versatile display can be panel mounted into a cutout in an enclosure or it can be mounted to an arm, stand, or hung on a surface. When panel mounted, the front bezel is IP66 rated and protected from liquids and dust. The TD-45-18 includes a wide range 9~36VDC power input and has an optional AC-to-DC power supply for AC powered applications. The same model is available in screen sizes from 7″ to 21.5″. These industrial touchscreen monitors can be connected to any computer, but most often times are connected to a fanless box PC. This offers a two piece rugged long life cycle solution. They can also be connected to other touchscreen panel PCs, where they operate as cloned displays or extended desktops. CONTACT US for a TD-45-18 quote today.

    SPECIFICATIONS

    Display

    Screen Size 18.5″
    Resolution 1366 x 768, Optional 1920 x 1080
    Screen Ratio 16:9
    Brightness 300 nits, Optional 1000 nit High Brightness
    Contrast Ratio 1000:1
    Viewing Angle 170º (H), 160º (V)
    Number of Colors Supported 16.7M

    Touch Screen

    Touch Screen Projected Capacitive, Resistive
    Light Transmission Over 80% (Resistive), Over 90% (P-Cap)
    Lifetime Usage 50,000 hrs

    External I/O ports

    USB 1x USB Type B Default (Optional RS-232 DB9)
    Video Inputs 1x HDMI, 1x DVI-D, 1x DisplayPort, 1x VGA
    Audio 1x Optional Speaker with 1x Audio Input
    Power Input Port 3-Pin DC-In (Phoenix Type)

    Power

    Input Voltage Range 9-32V DC
    Max Power Consumption 19.7W (Resistive), 30.2W (P-Cap)
    Standard Power Adapter Optional 12V AC/DC Adapter

    Multimedia

    Speakers Optional Speaker

    Thermal and Environmental

    Operating Temperature -20°C – 60°C
    (-4°F – 140°F)
    Storage Temperature -30°C – 70°C
    (-22°F – 158°F)
    Storage Humidity 10% – 90% Non-condensing
    Cooling Solution Passive – Fanless

    Enclosure

    Material Aluminum
    IP Rating IP66 Front Bezel
    Color Silver
    Mounting Options Panel Mount, VESA 100 Mount
    Approved Cleaning Solutions Acetone, Alcohol, Club Soda, Hydrochloric Acid, Methyl Alcohol, Mineral Spirits, Nitric Acid, Sulfuric Acid (low concentration), Vinegar, Warm Water

    Dimensions / Weight

    Weight 6.4 KG (14.1 lbs)
    Dimensions 499.6 x 314.6 x 59.9 mm (19.7 x 12.4 x 2.4 in)

    Certification

    Certifications CE, FCC Class A

    Warranty

    Warranty Up to 5 Years



    The post TD-45-18 – 18.5″ IP66 Industrial Touchscreen Monitor appeared first on Miller Technologies.

    ]]>         TD-45-17 – 17″ IP66 Industrial Touchscreen Monitor https://millertech.com/product/td-45-17-17-ip66-industrial-touchscreen-monitor/?utm_source=rss&utm_medium=rss&utm_campaign=td-45-17-17-ip66-industrial-touchscreen-monitor Wed, 29 Apr 2020 19:26:50 +0000 https://millertech.com/?post_type=product&p=6146
  • 17" LCD with 1280 x 1024 Resolution
  • Die Cast Aluminum Chassis
  • Optional High Brightness LCD and Auto Dimming
  • Wide Range DC 9~36V Power Input
  • Available with Resistive or Projected Capacitive Touchscreen
  • IP66 Compliant Front Panel

    • The post TD-45-17 – 17″ IP66 Industrial Touchscreen Monitor appeared first on Miller Technologies.

    ]]>     The TD-45-17 is a cost effective, versatile solution that fits the needs of many industrial applications. This display can be panel mounted, making its front bezel IP66 protected against dust and liquids. Or, it can be mounted to an arm, stand, or hung on a surface. The TD-45-17 can be connected to any computer including a rugged box PC or another touchscreen panel PC. This industrial touchscreen display includes VGA, DVI, HDMI, and DisplayPort video inputs. The same model is available in screen sizes from 7″ to 21.5″. These industrial touchscreen monitors may be mounted into control cabinets, integrated onto an OEM machine, or used in a manufacturing environment. CONTACT US for a TD-45-17 quote today.

    SPECIFICATIONS

    Display

    Screen Size 17″
    Resolution 1280 x 1024 (SXGA)
    Screen Ratio 4:3
    Brightness 350 nits, Optional 1000 nit High Brightness
    Contrast Ratio 1000:1
    Viewing Angle 170º (H), 160º (V)
    Number of Colors Supported 16.2M (Standard) / 16.7M (High Brightness)

    Touch Screen

    Touch Screen Projected Capacitive, Resistive
    Light Transmission Over 80% (Resistive), Over 90% (P-Cap)
    Lifetime Usage 30,000 hrs, 50,000 hrs (High Brightness)

    External I/O ports

    USB 1x USB Type B Default (Optional RS-232 DB9)
    Video Inputs 1x HDMI, 1x DVI-D, 1x DisplayPort, 1x VGA
    Audio 1x Optional Speaker with 1x Audio Input
    Power Input Port 3-Pin DC-In (Phoenix Type)

    Power

    Input Voltage Range 9-32V DC
    Max Power Consumption 11.6W (Resistive), 27.3W (P-Cap)
    Standard Power Adapter Optional 12V AC/DC Adapter

    Multimedia

    Speakers Optional Speaker

    Thermal and Environmental

    Operating Temperature -20°C – 60°C
    (-4°F – 140°F)
    Storage Temperature -30°C – 70°C
    (-22°F – 158°F)
    Storage Humidity 10% – 90% Non-condensing
    Cooling Solution Passive – Fanless

    Enclosure

    Material Aluminum
    IP Rating IP66 Front Bezel
    Color Silver
    Mounting Options Panel Mount, VESA 100 Mount
    Approved Cleaning Solutions Alcohol, Chlorine and Compounds, Glutaraldehyde, Hydrogen Peroxide, Ortho-phthalaldehyde (OPA), Quaternary Ammonium Compounds

    Dimensions / Weight

    Weight 5.9 KG (13.0 lbs)
    Dimensions 439 x 348 x 64.8 mm (17.3 x 13.7 x 2.6 in)

    Certification

    Certifications CE, FCC Class A

    Warranty

    Warranty Up to 5 Years



    The post TD-45-17 – 17″ IP66 Industrial Touchscreen Monitor appeared first on Miller Technologies.

    ]]>         TD-45-16 – 15.6″ IP66 Industrial Touchscreen Monitor https://millertech.com/product/td-45-16-15-6-ip66-industrial-touchscreen-monitor/?utm_source=rss&utm_medium=rss&utm_campaign=td-45-16-15-6-ip66-industrial-touchscreen-monitor Wed, 29 Apr 2020 19:16:49 +0000 https://millertech.com/?post_type=product&p=6140
  • 15.6" High Resolution LCD Touchscreen
  • Rugged Die Cast Aluminum Enclosure
  • Optional Sunlight Readable 1000 Nit LCD
  • IP66 Compliant Front Panel
  • Available with Resistive or Projected Capacitive Touchscreen
  • Wide Range DC 9~36V Power Input

    • The post TD-45-16 – 15.6″ IP66 Industrial Touchscreen Monitor appeared first on Miller Technologies.

    ]]>     The TD-45-16 is a versatile display that can be mounted into a cutout in an enclosure or it can be mounted to an arm, stand, or hung from a surface. When panel mounted, the front bezel is IP66 rated for protection from liquids and dust. The same model is available in screen sizes from 7″ to 21.5″ and can be connected to any computer. The TD-45-16 is often connected to a fanless box PC, offering a rugged, long-life solution. This display can also be connected to another touchscreen panel PC, where it can operate as a cloned display or an extended desktop. This touchscreen display includes a wide range 9~36VDC power input for applications that use their own DC voltage source. An optional AC-to-DC power supply is also available for AC powered applications. The TD-45-16 is ideal for mounting into control cabinets, integrating onto an OEM machine, or operating in a manufacturing environment. CONTACT US for a TD-45-16 quote today.

    SPECIFICATIONS

    Display

    Screen Size 15.6″
    Resolution 1366 x 768, Optional 1920 x 1080
    Screen Ratio 16:9
    Brightness 300 nits, Optional 1000 nit High Brightness
    Contrast Ratio 500:1
    Viewing Angle 160º (H), 160º (V)
    Number of Colors Supported 16.7M

    Touch Screen

    Touch Screen Projected Capacitive, Resistive
    Light Transmission Over 80% (Resistive), Over 90% (P-Cap)
    Lifetime Usage 50,000 hrs

    External I/O ports

    USB 1x USB Type B Default (Optional RS-232 DB9)
    Video Inputs 1x HDMI, 1x DVI-D, 1x DisplayPort, 1x VGA
    Audio 1x Optional Speaker with 1x Audio Input
    Power Input Port 3-Pin DC-In (Phoenix Type)

    Power

    Input Voltage Range 9-32V DC
    Max Power Consumption 12.2W (Resistive), 12.3W (P-Cap)
    Standard Power Adapter Optional 12V AC/DC Adapter

    Multimedia

    Speakers Optional Speaker

    Thermal and Environmental

    Operating Temperature -20°C – 60°C
    (-4°F – 140°F)
    Storage Temperature -30°C – 70°C
    (-22°F – 158°F)
    Storage Humidity 10% – 90% Non-condensing
    Cooling Solution Passive – Fanless

    Enclosure

    Material Aluminum
    IP Rating IP66 Front Bezel
    Color Silver
    Mounting Options Panel Mount, VESA 100 Mount
    Approved Cleaning Solutions Alcohol, Chlorine and Compounds, Glutaraldehyde, Hydrogen Peroxide, Ortho-phthalaldehyde (OPA), Quaternary Ammonium Compounds

    Dimensions / Weight

    Weight 4.4 KG (9.7 lbs)
    Dimensions 412 x 277.5 x 58.9 mm (16.2 x 10.9 x 2.3 in)

    Certification

    Certifications CE, FCC Class A

    Warranty

    Warranty Up to 5 Years



    The post TD-45-16 – 15.6″ IP66 Industrial Touchscreen Monitor appeared first on Miller Technologies.

    ]]>         TD-45-15 – 15″ IP66 Industrial Touchscreen Monitor https://millertech.com/product/td-45-15-15-ip66-industrial-touchscreen-monitor/?utm_source=rss&utm_medium=rss&utm_campaign=td-45-15-15-ip66-industrial-touchscreen-monitor Wed, 29 Apr 2020 19:05:21 +0000 https://millertech.com/?post_type=product&p=6134
  • 15" Touchscreen with Optional Sunlight Readable 1000 Nit LCD
  • Aluminum Chassis for Industrial Strength
  • IP66 Compliant Front Panel
  • Available with Resistive or Projected Capacitive Touchscreen
  • Wide Range DC 9~36V Power Input
  • Full Flat Front Panel

    • The post TD-45-15 – 15″ IP66 Industrial Touchscreen Monitor appeared first on Miller Technologies.

    ]]>     The TD-45-15 is an aluminum panel display made for industrial environments. This versatile display can be panel mounted into a cutout in an enclosure or it can be mounted to an arm, stand, or hung on a surface. When panel mounted, the front bezel is IP66 rated and protected from liquids and dust. The same model is available in screen sizes from 7″ to 21.5″ to meet the needs of most applications. The TD-45-15 can be connected to a box PC, offering a rugged, long-life solution, or connected to other touchscreen PCs, where it can operate as a cloned display or as an extended desktop. This display includes VGA, DVI, HDMI, and DisplayPort video inputs. CONTACT US for a TD-45-15 quote today.

    SPECIFICATIONS

    Display

    Screen Size 15″
    Resolution 1024 x 768 (XGA)
    Screen Ratio 4:3
    Brightness 420 nits, Optional 1000 nit High Brightness
    Contrast Ratio 800:1
    Viewing Angle 160º (H), 160º (V)
    Number of Colors Supported 16.2M, 262K

    Touch Screen

    Touch Screen Projected Capacitive, Resistive
    Light Transmission Over 80% (Resistive), Over 90% (P-Cap)
    Lifetime Usage 30,000 hrs

    External I/O ports

    USB 1x USB Type B Default (Optional RS-232 DB9)
    Video Inputs 1x HDMI, 1x DVI-D, 1x DisplayPort, 1x VGA
    Audio 1x Optional Speaker with 1x Audio Input
    Power Input Port 3-Pin DC-In (Phoenix Type)

    Power

    Input Voltage Range 9-32V DC
    Max Power Consumption 12.5W (Resistive), 17.6W (P-Cap)
    Standard Power Adapter Optional 12V AC/DC Adapter

    Multimedia

    Speakers Optional Speaker

    Thermal and Environmental

    Operating Temperature -20°C – 60°C
    (-4°F – 140°F)
    Storage Temperature -30°C – 70°C
    (-22°F – 158°F)
    Storage Humidity 10% – 90% Non-condensing
    Cooling Solution Passive – Fanless

    Enclosure

    Material Aluminum
    IP Rating IP66 Front Bezel
    Color Silver
    Mounting Options Panel Mount, VESA 100 Mount
    Approved Cleaning Solutions Alcohol, Chlorine and Compounds, Glutaraldehyde, Hydrogen Peroxide, Ortho-phthalaldehyde (OPA), Quaternary Ammonium Compounds

    Dimensions / Weight

    Weight 4.3 KG (9.5 lbs)
    Dimensions 410 x 310 x 54.6 mm (16.1 x 12.2 x 2.1 in)

    Certification

    Certifications CE, FCC Class A

    Warranty

    Warranty Up to 5 Years



    The post TD-45-15 – 15″ IP66 Industrial Touchscreen Monitor appeared first on Miller Technologies.

    ]]>
